Description

X-Laser X-Beams have long been the top choice of performers, designers and installers for high brightness, room filling aerial laser effects at an affordable price. The X-Beam 2500 continues that tradition by using superior optics and high spectral laser sources to deliver a brightness greater than laser systems rated at double it’s power. Create dramatic, stunning, bright aerial beam effects quickly and easily via ILDA or DMX control. With auto, sound and 100+ built-in effects, the X-Beam 2500 is perfect for fixed installations, light touring, and multiple other uses where big, bold aerial effects are needed at a value price point.

Highlights

• X-Beam 2500: Big, Bold, Room-Filling Aerial Laser System

  The X-Beam 2500 delivers high powered, room-filling, RGB aerial laser effects, adding a whole new element to any lighting installation, venue or mobile DJ lighting rig.

• Roadworthy, rugged Field Serviceable Optics
  Easy access and reliability are essential on and off the road. The X-Beam 2500 makes field service simple with ‘finger screw’ style
finely threaded optics mounts.

• Create ultra-thick, high visibility beams via ILDA & DMX & more

  The X-Beam 2500 has the ability to recall hundreds of patterns via DMX, auto & sound modes, or allow for fully customized control via ILDA & Pangolin QuickshowXL software.

Features

• 2.5W of apparent brightness
• High-speed aerial beam scanners
• Full color aerial beam effects
• Ultra-thick, high visibility beams
• Manual X/Y Zoom Control
• Total Control via DMX and ILDA
• No external power supply required
• Field serviceable optical alignment
• Adjustable Sound and Auto Modes
• X-Laser No-Hassle Warranty
• 26 Point quality control inspection before shipping
• Ask about our EZ Variance Kit to acquire your variance quickly and easily

Specifications

• Control: 12-channel DMX, Sound, Auto
• Scanners: 15K , max andle of 40 degrees
• Settings interface: DIP switches
• Color modulation: TTL (Max Power)
• Laser energy: 1.6J CW
• Physical: 15.25”L x 14.5”W x 7” H, 16 lbs
• Housing Type: Anodized Type II aluminum
• Power Draw: 35W typical, 200W peak
• Power: 110-230V, 50-60Hz, #-pin IEC
• Beam Divergence: 1.5-3 mRad
• Beam Source: DPSS/Direct Diode 450, 532, 638
• Apparent Brightness: ~2,500mW
• Cooling: TEC, filtered forced air
• FDA/IEC hazard class: Class 4
• International Safety: IEC 60825-1 ed. 2007
• FDA/CDRH: 21CFR1040.10 and 1040.11(c)
• Canadian safety: CSA C.22.2 No. 60950-1
• EU safety: EN 60825-1, EN 60950

What's In The Box

X-Beam 2500
User Training DVD
User Manual
Warranty Information
Beam Block Foil
